Cable tray cable fixing clips

Cable tray fixing clips are hardware components used to secure cable trays, covers, or support them from rods, offering quick installation, stability, and corrosion resistance. Types of Cable Tray Fixing Clips1.

Tray-to-

Rod Clips: These clips attach cable trays or baskets to threaded rods, providing vertical support. They typically feature a 68mm arm for holding small cable containment systems and are compatible with standard rod sizes like 1/4", 3/8", or 1/2". They are ideal for suspending trays from ceilings or overhead structures.

2. Cover Fixing Clips: Used to secure cable tray covers, these clips snap onto the tray edge and grip the cover. Many are made from 304 stainless steel, offering rust and corrosion resistance.

They can be installed by hand without welding or special tools, and some models allow screws for a more permanent hold. These clips are reusable and cost-effective, suitable for maintenance access. 3.

Clamp and Connector Clips: Clamp connectors join two trays in a straight line or after bending. Hanging clips attach to the sides of trays to suspend them from rods, requiring nuts and washers for secure installation. These clips help maintain tray alignment and prevent sagging.

4.

Light-

Duty Utility Clips: Products like the Walraven Britclips® are designed for light-duty applications, providing a simple and reliable method to fix cable trays or brackets in place. They are suitable for smaller installations or where minimal load is expected.

Materials and Benefits

Materials: Commonly zinc-plated steel or stainless steel (304 grade) for corrosion resistance. Benefits: Quick installation, reusable, cost-effective, and provide stable support for cables and trays. They also allow excellent ventilation and prevent sagging of cables.

Installation Considerations

Ensure compatibility with tray width and rod size. Use appropriate nuts, washers, and threaded rods for hanging clips. For cover clips, check if a screw is needed for permanent fixation.

Consider load capacity; some systems support up to 280 lbs per foot when properly supported. Cable tray fixing clips are essential for safe, organized, and accessible cable management, whether for industrial, commercial, or light-duty installations.
