How to connect a wireless AP to a switch

Fiber and communications infrastructure knowledge brief Published 31 Jan 2022

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

You can connect a network switch to a wireless network by linking it to a wireless router or access point using an Ethernet cable, allowing wired devices to access Wi-Fi indirectly.

Required Equipment

To connect a switch to a wireless network, you will need: Network Switch: Choose one with enough ports for your devices and suitable speed (e.g., Gigabit). Wireless Router or Access Point (WAP): This will provide the Wi-Fi network. Ethernet Cables: To connect the switch to the router or WAP.

Power Source: For the switch and router. Devices to Connect: Computers, printers, or other network-enabled devices.

Step-by-

Step Connection

Power On the Devices: Plug in the switch and router/WAP to a power source. Connect the Switch to the Router/WAP: Use an Ethernet cable to connect one of the switch's ports to a LAN port on the router or WAP. This allows the switch to access the wireless network indirectly.

Connect Devices to the Switch: Plug your wired devices into the remaining ports on the switch. They will now have network access through the router's Wi-Fi. Verify Connectivity: Test each device to ensure it can access the internet or network resources.

Adjust I

P settings if necessary, or ensure DHCP is enabled on the router. Optional: Using a Wireless Access PointIf your switch is far from the router, you can use a wireless access point to bridge the wired switch to the Wi-Fi network.

Connect the WA

P to the switch via Ethernet, configure it to join the existing Wi-Fi network, and your wired devices will gain wireless access.

Tips for Optimal Setup

Place the router or WAP in a central location for better coverage. Use high-quality Ethernet cables to maintain speed and reliability. For larger networks, consider managed switches to configure VLANs and optimize traffic.

By following these steps, you can effectively integrate a network switch into a wireless network, expanding connectivity for multiple wired devices while leveraging your existing Wi-Fi infrastructure.
