Drilling locations for stainless steel cable trays

Fiber and communications infrastructure knowledge brief Published 08 Jan 2022

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Use cobalt or TiN-coated HSS drill bits, low speed, steady pressure, and cutting fluid to drill stainless steel cable trays safely and efficiently.

Recommended Drill Bits and Tools

Cobalt drill bits (M35 or M42) or TiN-coated HSS bits are ideal for stainless steel due to their heat resistance and durability. Step drills can be used for deeper holes to reduce heat buildup and allow chip removal. Drill press or hand drill with adjustable speed is recommended.

Ensure the tray is clamped securely to prevent movement.

Drilling Technique

Mark the hole location using a scribe or 3-point punch to prevent the bit from wandering. Apply cutting fluid generously to reduce friction, heat, and work hardening. Drill at low speed (typically 300–500 RPM for hand drills) with steady, consistent pressure.

Back out the bit periodically to clear chips and prevent overheating. Avoid pausing mid-cut, as stainless steel work-hardens quickly, making subsequent drilling more difficult.

Cooling and Chip Management

Use spray, flood, or drip cutting oil to keep the bit cool and lubricated. Observe the swarf: clean, short, helical chips indicate proper speed and feed; dark or irregular chips suggest overheating or incorrect technique.

Safety and Finishing

Wear safety goggles, gloves, and dust mask to protect against sharp swarf and metal particles. After drilling, deburr edges using a file or sandpaper to prevent injuries and maintain tray integrity. Avoid excessive pressure to prevent bit breakage and tray deformation.

Best Practices

Drill between existing holes when possible to maintain structural strength. Provide rigid support for the tray to prevent chipping at edges. For repetitive or precise drilling, consider pre-drilled trays or drilling jigs for splice connections.

By following these methods, drilling stainless steel cable trays can be performed efficiently, safely, and with minimal wear on tools while preserving the tray's structural integrity.
