What is needed for cable trays

Fiber and communications infrastructure knowledge brief Published 09 Jan 2022

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Cable trays require proper selection of type, material, supports, fittings, and compliance with safety standards to ensure secure and efficient cable management.

Key Components

A complete cable tray system consists of several integral parts: straight sections for main cable runs, fittings such as horizontal and vertical bends, tees, and crosses to route cables, reducers to connect trays of different widths, covers to protect cables from dust and debris, splice plates to join sections, hold-down clamps for securing covers, and drop-outs for vertical cable exits. Supports like trapeze hangers, wall brackets, or center-span supports anchor the system to the building structure.

Materials

Cable trays are commonly made from steel, aluminum, stainless steel, or fiber-reinforced plastic (FRP). Steel offers high strength and load capacity but is heavier and prone to corrosion. Aluminum is lightweight and corrosion-resistant, ideal for high-rise buildings or areas where weight reduction is important.

FR

P is suitable for corrosive environments. Material selection depends on environmental conditions, load requirements, and regulatory compliance.

Types of Cable Trays

Ladder trays: Best for heavy-duty power cables and high-heat environments; allow excellent ventilation. Perforated trays: Provide airflow and moderate cable support; suitable for structured cabling. Solid-bottom trays: Offer maximum protection against dust and EMI; may reduce heat dissipation.

Wire mesh trays: Lightweight and flexible; ideal for fiber optic and low-voltage cables. Channel trays: Designed for small cable runs and light-duty applications.

Installation Considerations

Cable types: Use conductors rated for open-air environments, such as Tray Rated (TC) or Metal-Clad (MC) cables. Clearances: Maintain at least 12 inches of vertical clearance for installation and maintenance. Fill limits: Power cables should not exceed 40% of tray cross-section; control cables up to 50%.

Separation: High-power and low-power cables must be separated to prevent electromagnetic interference (EMI). Supports and spacing: Rung spacing for ladder trays is typically 6–9 inches; solid or ventilated trays require proper support to prevent sagging.

Regulatory Compliance

Ensure the cable tray system meets NEC, NEMA, and IEC standards for safety, grounding, and load capacity. Metallic trays can serve as equipment grounding conductors if compliant. Avoid installation in prohibited areas like hoistways or enclosed spaces.

By carefully selecting the type, material, components, and installation method, and adhering to safety and regulatory standards, cable trays provide a reliable, organized, and maintainable solution for electrical and communication cabling.
