Fiber optic patch cord connector assembly price

Fiber optic patch cord assembly prices vary widely depending on fiber type, connector type, length, and customization, typically ranging from a few dollars for standard cords to higher costs for specialized or armored assemblies.

Pricing Overview

Fiber optic patch cord prices are influenced by several factors: Fiber Type: Singlemode (OS1/OS2) and multimode (OM3, OM4, OM5) fibers have different costs, with OM5 and high-performance multimode fibers generally priced higher due to advanced transmission capabilities. Connector Type: Common connectors include LC, SC, MPO/MTP, and APC/UPC finishes. MPO/MTP connectors, especially for 12F or 24F cores, require precise alignment and polishing, increasing the cost.

Cable Length: Prices increase linearly with length, but the type of jacket (LSZH, OFNR, OFNP) and armoring can significantly affect the final price. Customization: Custom lengths, connector types, and polish options are available from vendors like Fibertronics, Corning, and RLH Industries, often at a premium.

Example Price Ranges

Standard Singlemode Patch Cords (1–5 meters): Typically $5–$15 per unit for LC/SC connectors. Multimode OM3/OM4 Patch Cords: Around $6–$20 per unit depending on length and connector type.

Armored or LSZ

H Cables: Can cost 20–50% more than standard cords due to added protection and compliance with safety standards. High-Fiber-Count Assemblies (12F, 24F MPO/MTP): Prices vary widely, often $50–$150 per assembly depending on length and connector quality.

Vendor Options

Mouser Electronics: Offers a wide inventory of patch cord assemblies with datasheets and pricing for standard and custom options. Corning: Provides factory-terminated cables, including single-fiber and high-fiber-count assemblies, with quick delivery programs.

RL

H Industries: Publishes a detailed price list for fiber cable assemblies and supports special project inquiries. Fibertronics, Inc.: Offers both standard and fully customized patch cords with various fiber types, connector finishes, and jacket options, all assembled in the USA.

Recommendations

For budget-conscious projects, standard singlemode or multimode cords with LC/SC connectors are cost-effective. For data centers or harsh environments, consider LSZH or armored cables for durability and safety compliance. For high-density or specialized applications, MPO/MTP assemblies or custom lengths may be necessary, with prices reflecting the complexity.

For exact pricing, it is recommended to contact vendors directly or check their online catalogs, as prices fluctuate based on fiber type, connector, length, and order volume.
