Optical Module Interfaces and Ports

Fiber and communications infrastructure knowledge brief Published 09 Dec 2021

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Optical modules typically use LC duplex, LC simplex, or MTP/MPO ports to connect fiber optic cables, while electrical modules use RJ45 ports for copper connections.

Overview of Optical Module Ports

An optical module is a hot-pluggable transceiver that converts electrical signals to optical signals and vice versa, enabling high-bandwidth data communication over fiber optic cables (Wikipedia). The interface type port refers to the physical connector on the module that links it to the fiber network. Common optical module ports include: LC Duplex: Two fibers in a single connector, widely used for short- and long-distance links.

L

C Simplex: Single fiber connector, often used in specialized applications. MTP/MPO: Multi-fiber connectors for high-density applications, such as data centers (Wikipedia). Electrical vs Optical PortsOptical modules differ from electrical port modules, which use RJ45 connectors and UTP copper cables for short-distance transmission (less than 100 meters).

Key differences include: Interface: Optical modules use fiber connectors (LC, MTP/MPO), while electrical modules use RJ45. Transmission medium: Optical modules transmit light signals through fiber; electrical modules transmit electrical signals through copper cables. Wavelength: Optical modules operate at specific wavelengths (e.g., 850 nm, 1310 nm, 1550 nm), whereas electrical modules do not have a wavelength parameter.

Components: Optical modules contain lasers or LEDs for signal transmission; electrical modules lack these optical components.

Form Factors and Standards

Optical modules follow multi-source agreements (MSAs) that define form factors and electrical interfaces, such as: SFP (Small Form-factor Pluggable)SFP+ (10G)QSFP/QSFP28 (40G/100G)CFP/CFP2/CFP4 (100G and above) These form factors determine the type of port and connector used, as well as compatibility with switches, routers, and network interface cards.

Summary

The optical module interface type port is primarily defined by the connector used to link the module to fiber optic cables, with LC duplex, LC simplex, and MTP/MPO being the most common. Electrical port modules, in contrast, use RJ45 connectors for copper cabling. Understanding the port type is essential for ensuring compatibility with network devices and the intended transmission medium.
