Air-blown optical cable models and specifications

Fiber and communications infrastructure knowledge brief Published 12 Feb 2025

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Air-blown optical cables are lightweight, high-capacity fiber cables designed for installation via compressed air, offering flexible deployment, low friction, and robust mechanical and optical performance. General FeaturesAir-blown optical cables are engineered for long-distance fiber deployment using compressed air, with small diameters, light weight, and low sheath friction to maximize blowing distance and installation efficiency. Key features include: Mechanical Strength: Aramid yarn or central strength members provide tensile load support and resistance to bending.

Environmental Protection: Water-blocking components, UV-stabilized jackets, and flame-resistant options for riser and plenum applications. Flexible Fiber Deployment: Fibers can be added or replaced without disturbing the duct system, supporting modular network expansion. Fiber Types and Optical ParametersAir-blown cables support both single-mode (SMF) and multimode (MMF) fibers, with specifications for attenuation, bandwidth, and Ethernet compatibility: Fiber TypeMax Attenuation (dB/km)Min Bandwidth (MHz·km)10G Ethernet Max Distance (m)40/100G Ethernet SupportOM1 62.

5/1253. 5 @ 850 nm200300YesOM2 50/1253. 5 @ 850 nm500600YesOM3 50/1253.

0 @ 850 nm15001000YesOM4 50/1253. 0 @ 850 nm35001040YesSM OS2 (G. 652D/G.

657. A1)0. 4 @ 1310/1550 nmN/AN/AYes Bend-insensitive fibers (BIF) are commonly used to reduce signal loss in tight bends.

Mechanical and Physical ParametersAir-blown cables are available in various fiber counts and diameters, with typical mechanical specifications: ModelFiber CountNominal Diameter (mm)Weight (kg/km)Max Tensile Load (Short/Long Term, N)Min Bend Radius (Short/Long Term, mm)ENT-A SM-663. 69. 5445 / 13330 / 20ENT-A SM-24243.

6–3. 811–14445 / 13330 / 20ENT-A SM-72724. 520.

81600 / 45090 / 45ENT-A SM-96964. 523. 81600 / 45090 / 45 Cables are designed for micro-duct compatibility, often fitting 6 mm ID ducts, enabling high-density fiber pathways.

Construction and DesignAir-blown cables typically feature: Loose Tube or Central Tube Design: Fibers are color-coded and gel-filled for protection.

All-

Dielectric Construction: No metallic components, suitable for environments requiring non-conductive cables. Outer Jacket: PE or LSZH materials, UV-stabilized, and water-blocked for durability. Ripcords: Facilitate easy jacket removal during installation.

Applications

Data center interconnectsHorizontal and backbone distributionLow-cost fiber upgrades and migrationInternal and external micro-duct systems Installation AdvantagesBlowing Distance: Long-distance fiber deployment without splicing. Modular Expansion: Fibers can be added later without replacing the duct. Reduced Labor and Cost: Faster installation and lower material handling requirements.

Air-blown optical cables provide a highly flexible, reliable, and scalable solution for modern fiber networks, combining mechanical robustness, optical performance, and ease of installation.
