The 48 Core fiber distribution box features a two-panel flip-up design, providing a separate working area for effortless management by the installer. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. Efficiently manage and distribute up to 48 fiber optic connections with the robust, weatherproof SJ ODB M12 fiber distribution box, ideal for telecommunications, data centers, and versatile network applications. Industray Standard User Interface, with high impact plastic; 2. Can max contain 48 ports FTTH Drop.
