Relay Protection Telecommunication Equipment Chassis Dimensions

Relay protection and telecommunication equipment typically use 19-inch rack-mountable chassis, with heights measured in rack units (U), such as 3U (5. 25”) or 6U (10. 50”), and standard widths of 19 inches (482.

6 mm).

Standard Rack and Chassis Dimensions

Width: Most telecommunication and relay protection equipment is designed for 19-inch racks, where the 19 inches (482. 6 mm) includes the mounting ears on each side for securing the chassis to the rack frame. Height: Equipment height is standardized in rack units (U), where 1U = 1.

75 inches (44. 45 mm). Common chassis heights for relay protection systems include 3U (5.

25”) and 6U (10. 50”). Depth: Depth varies depending on the equipment and manufacturer.

Typical relay racks may have depths ranging from 12” to 16” for smaller wall-mounted units, while full cabinets can be deeper to accommodate larger modules and cable management. Mounting: Chassis are often mounted on rails or slides to allow easy access for maintenance. Rails may be set back from the front and rear of the rack by several inches, and some systems include tilt or slide mechanisms for inspection.

Example: RFL GARD 8000 Series3U chassis: 5. 25” high, supports up to two teleprotection or protective relay modules. 6U chassis: 10.

50” high, supports up to eight modules. Width: Standard 19-inch rack-mountable. Additional features: Redundant controllers and power supplies are optional; all modules meet ANSI and IEC dielectric and transient withstand standards.

Standards and ComplianceETSI 300 119-2 and IEC Subcommittee 48D define engineering requirements for racks and cabinets housing telecommunication equipment.

NEB

S GR-63-CORE specifies seismic and structural requirements for telecom equipment racks, including dynamic load support and mounting stability. Material and construction: Typical racks use steel with powder-coated finishes, ventilation grills, and fire-retardant coatings, with minimum thicknesses around 1. 2 mm.

Summary

Relay protection and telecommunication equipment chassis are designed to fit standard 19-inch racks, with heights in multiples of 1U (commonly 3U or 6U), and variable depths depending on the application. Compliance with ETSI, IEC, and NEBS standards ensures proper mounting, structural integrity, and safety in operational environments. This allows for modular installation, easy maintenance, and compatibility with standard rack infrastructure.
