Number of optical modules in the switch

Fiber and communications infrastructure knowledge brief Published 12 Jan 2022

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

The number of optical modules in a switch depends on the switch model, port count, and port speed, ranging from a few modules in small switches to thousands in high-performance data center switches.

Factors Affecting Optical Module Count

Port Count and Speed: Each switch port that supports fiber connectivity typically requires one optical module. For example, a 32-port OSFP switch with 400Gbps ports may use 64 optical channels, requiring 64 modules for full connectivity. Module Type: Common optical modules include SFP, SFP+, SFP28, QSFP, and OSFP.

SF

P modules support speeds from 1Gbps to 25Gbps, while QSFP and OSFP modules support 100Gbps to 800Gbps or higher. Network Architecture: In multi-layer switch architectures, the number of optical modules scales with the number of leaf and spine switches. For instance, in NVIDIA's A100 SuperPOD with 140 servers, 6,720 200G optical modules are used across 140 switches to support full connectivity.

Co-

Packaged Optics (CPO): Modern high-bandwidth switches integrate optical engines directly with the ASIC. For example, Broadcom's Tomahawk-5 CPO switch has eight 6. 4Tbps optical engines, supporting 64 x 800Gbps or 128 x 400Gbps ports, effectively replacing traditional pluggable modules.

Examples

Small Switches: A 24-port SFP+ switch may require 24 optical modules for full fiber connectivity.

High-

Performance Data Center Switches: A 144-port 800Gbps switch may require hundreds of optical modules, or use CPO to integrate optics directly, reducing the need for individual pluggable modules. SuperPOD Configurations: Large GPU clusters can require thousands of optical modules to connect leaf and spine switches, depending on the number of nodes and network layers.

Summary

The exact number of optical modules in a switch is not fixed and depends on port count, speed, module type, and network design. Small enterprise switches may use a few dozen modules, while large-scale data center switches or GPU clusters can require hundreds to thousands of optical modules, or leverage co-packaged optics to integrate them directly with the switch ASIC.
